IEC DC CHARGING PLUG CCS Type2

Product application: Electric vehicle electrical connection

Features
·Meet IEC 62196-1/3  regulations and requirements;
·Nice appearance, Integrated molding hand-held ergonomic design, easy plug;
·Excellent protection performance, protection grade IP67 MAX (working condition);
·Product whole body insulation,feel comfortable,safe and reliable;
·Product design has over temperature protection function.

contact us

More Details

Key Features

Applied Materials
·Case Material: Thermoplastic, flame retardant grade UL94 V-0
·Pin: Copper alloy, silver + thermoplastic on the top

Custom Specification
·Shell color: White/Black/custom
·Shell marking: Can be required by the customer
·Temperature sensor: Optional PT1000
·Cable length: Can be required by the customer
·Cable color: Black
·Wire end connection copper nose: Can be required by the customer

Mechanical Properties
·Mechanical life: no-load plug in/pull out> 10000 times
·Coupled insertion force:F<100N
·Impat of external force: can afford 1m drop and 2t vehicle run over pressure

Electrical Performance
·Rated current: 80/100/125/150/200/250/300/350
·Rated voltage: 1000V
·Insulation resistance: >2000MΩ (DC1000V)
·Terminal temperature rise: <50K
·Withstand voltage: 3500V
·Contact Resistance:0.5mΩ Max

EnvironmentalPerformance
·Operating temperature:-40℃~+50℃
