Product application: Electric vehicle electrical connection
Features
·Meet GB/T 20234.1/3-2023 regulations and requirements;
·Nice appearance, integrated molding hand-held ergonomic design, easy plug;
·Safety pins insulated head design to prevent accidental direct contact with staff;
·Excellent protection performance, protection grade lP67 MAX (working condition);
·The product is designed with motor type electronic locking device, and has locking signal feedback confirmation function;
·Product design has over temperature protection function;
·All systems with standard emergency unlock button convenient, fast, safe and reliable;
·Zinc alloy multi-stage lock clamp, anti-stripping line, stable as a rock;
·External storage bin design, support lossless, quick replacement easy maintenance.
More Details
Key Features
Custom Specification
·Shell color: White/Black/custom
·Shell marking: Can be required by the customer
·Temperature sensor: Optional PT1000/NTC/temperature control switch
·Electronic lock control status: optional normally closed/normally open
·Cable length: Can be required by the customer
·Cable color: Black
·Wire end connection copper nose: Can be required by the customer
Mechanical Properties
·Mechanical life: no-load plug in/pull out> 10000 times
·Coupled insertion force:<140N
·Impat of external force: can afford 1m drop and 2t vehicle run over pressure
Electrical Performance
·Rated current: 63/125/200/250/300A
·Rated voltage:1000V
·Insulation resistance:>2000MΩ(DC1000V)
·Terminal temperature rise: <50K
·Withstand voltage: 3500V
·Contact Resistance: 0.5mΩ Max
Applied Materials
·Case Material: Thermoplastic, flame retardant grade UL94 V-0
·Pin: T1 Red Copper, silver + thermoplastic on the top
Environmental Performance
·Operatingtemperature:40℃~+50℃
